Firmware Version 9.2(3) for Cisco Unified IP Phone Models7911G and 7906G

The 9.2(3) firmware image within the installation program supports the Skinny Client Control Protocol (SCCP) for the following Cisco Unified IP Phones :

Changing the firmware is a relatively easy task. It involves having a tftp server on the network that serves the firmware files to the phone upon bootup. After registering for a free account on the Cisco website, I was able to download the SIP9-3-1-1S firmware files and followed the instructions at this link to upgrade 7911 phones to SIP firmware. The Cisco Unified IP Phone Model 7911G and 7906G Firmware version 9.2 (3) is also supplied in a zip file, as an alternative in case a Cisco Unified CallManager is not available to run the executable installer program. The name of this file is cmterm-79117906-sccp.9-2-3.zip. SCCP & SIP Firmware download for the Cisco 7906 & 7911 IP phone. Information on how to configure CallManager Express to upgrade your IP phone, can be found in our Cisco CallManager Express Setup for IP Phone Firmware Upgrade article. SCCP Firmware Version: 9.2.1 Filename: cmterm-79117906-sccp.9-2-1.tar SIP Firmware Version: 9.2.1.

Before beginning, the Cisco phone must have the SIP firmware installed. Proof of this is the SIP logo in the upper right corner of the phone's screen. Cisco has the SIP phone image available to the public at ftp.cisco.com. Also make sure your device firmware version is 8.2 or better. EDIT 4/12/20 @ 10:10 PM EST: I was a dummy haha, you have to load the xml WITH the config AFTER you flash it. DuhI can't provision the phone because the butt.

• Cisco Unified IP Phone 7911G
• Cisco Unified IP Phone 7906G

This firmware version is supported on Cisco Unified CallManager Release 5.0 and later, and Cisco Unified CallManager Releases 4.3, 4.2, 4.1, 4.0, and 3.3.

Note: 7906G isnot supported on 4.0, 5.0(1) and 5.0(2) Cisco Unified Call Manager releases.

Release Notes

For a list of Resolved Problems and KnownProblems with this firmware version, you can obtain the Firmware Release Notesin English by clicking the following URL:
http://www.cisco.com/en/US/docs/voice_ip_comm/cuipph/firmware/9_2_3/english/release/notes/7900_923.html

For all Phone firmware Release Notes, clickthe following URL:
http://www.cisco.com/en/US/products/hw/phones/ps379/prod_release_notes_list.html

For all phone documentation, click the following URL:
http://www.cisco.com/en/US/products/hw/phones/ps379/tsd_products_support_series_home.html

Image Authentication Support

Cisco providesimage authentication with its various IP phone protocols. Imageauthentication allows the phone to detect if the image has been tampered withbefore it is programmed into the phone. If the image fails the authenticationprocess then the phone will reject the image. Image authentication occursthrough signed files. All Cisco Unified IP Phone 7911G and 7906G loads are signedand can only be upgraded or downgraded to other signed releases.

The 9.2(3)firmware uses signed (authenticated) files. This step improves IP phonesecurity on the Cisco Unified IP Phone 7911Gand 7906G.

Installing the Firmware Load

Before using the CiscoUnified IP Phone 7911G and 7906Gwith Cisco Unified CallManager release 3.3 or later,you must install the latest firmware on all Cisco Unified CallManagerservers in the cluster.

Note: If youhave a Cisco Unified CallManager on Release 3.0, 3.1,or 3.2, do NOT install this firmware. You must firstupgrade your Cisco Unified CallManager to thecompatible releases listed in Table 1 or Table2.

Table 1:Compatible Cisco Unified Call Manager Release for 7911G(No support for 7906G in these releases)

Call Manager Version	Executable on Software Page
3.3(5)SR1 or later & ciscocm.3-3-DevPack-64.exe	ciscocm.3-3-5-sr1.exe; ciscocm.3-3-DevPack-64.exe
4.0(2)SR2b or later & ciscocm.4-0-DevPack-43.exe	ciscocm.4-0-2a-sr2b.exe; ciscocm.4-0-DevPack-43.exe
4.1(3)SR1 or later & ciscocm.4-1-DevPack-23.exe	ciscocm.4-1-3-sr1.exe; ciscocm.4-1-DevPack-23.exe

Table 2:Compatible Cisco Unified Call Manager Release that supports both 7906G and 7911G

Call Manager Version	Executable on Software Page
3.3(5)SR2 or later & ciscocm.3-3-DevPack-68.1.exe or later	ciscocm.3-3-5-sr2.exe; ciscocm.3-3-DevPack-68.1.exe
4.1(3)SR3a or later & ciscocm.4-1-DevPack-28.2.exe or later	ciscocm.4-1-3-sr3a.exe; ciscocm.4-1-DevPack-28.2.exe
4.2(1)SR1 or later & ciscocm.4-2-1-DevPack-03.3.exe or later	ciscocm.4-2-1-sr1.exe; ciscocm.4-2-1-DevPack-03.3.exe

Cisco Unified CallManagerVoice Software download page: http://www.cisco.com/kobayashi/sw-center/sw-voice.shtml

The 8.0(1)firmware release has been made available on Cisco Unified CallManagerinstallation CDs; however, it will not be made available on Cisco.com due toadditional bugs filed during final testing. Cisco recommends that you insteaduse the updated 9.2(3) firmware load, which is now available on Cisco.com. Thisrecommendation is limited to this specific firmware release and has no bearingon any other software or firmware available on Cisco Unified CallManager CDs.

The 9.2(3) installationprograms for the Cisco Unified IP Phone 7911G and 7906 G are listed below.

Note: For the Cisco UnifiedIP phone 7911G and 7906G,you should not add the .loads extension to the firmware versionname in the Cisco Unified CallManager database.

Cisco Unified IP Phone Model 7911Gand 7906G Installation Instructions

Cisco 7911 Sip Firmware Upgrade

Perform the following procedure:

1. Click the following URL: http://www.cisco.com/cgi-bin/tablebuild.pl/ip-7900ser
2. Download the file that is listed in Table 3 to your hard drive.

Cisco 7911g Sip Firmware Download

Table 3: Cisco Unified IP Phone Models 7911G and 7906G Firmware Loads

Cisco Unified IP Phone Models	CallManager Version	Executable on Software Download Page on CCO	MD5 hash
7911G and/or 7906G	5.0(4) and later	cmterm-7911_7906-sccp.9-2-3.cop.sgn	6b4e87d4b5ff48090632810c7542044e
7911G and/or 7906G	earlier than 5.0	cmterm-7911_7906-sccp.9-2-3.exe	N/A

Note: 7906G issupport requires Cisco Unified Call Manager release 5.0(3) or later.

Please note that different versions of the installer are neededfor different Cisco Unified CallManagerreleases. Cisco Unified CallManager releasesearlier than 5.0 are based on a windows server platform. For Cicso Unified CallManager release5.0 and later are based on a Linux server platform.

When using Cisco Unified CallManagerRelease 5.0 or later

For Cisco Unified CallManager5.0, you must do all software installations and upgrades by using the SoftwareUpgrades menu options. The system can upload and process only software thatCisco approved. You cannot install or use third-party or Windows-basedsoftware applications that you may have been using with a previous version ofCisco Unified CallManager with Cisco Unified CallManager 5.0.

1. Using your web browser, login to the Cisco IPT Platform Administration web page
2. Under the Software Upgrades menu, select Install/Upgrade.
3. Fill in the appropriate values in the Software Location section for the file you downloaded above, and click Next.
4. In the Available Software drop-down box, select the file you downloaded above, and click Next.
5. Enusre that the downloaded file has the same MD5 hash value as listed in Table 3.
6. Click Next.
7. In the Warning box, verify you have selected the correct firmware, then click Install.
8. Ensure that you received a Success message.

When Using Cisco Unified CallManagerearlier than Release 5.0

1. Login to the console of the Cisco Unified CallManager Server where you downloaded the installer.
2. Note the location where you saved the downloaded file.
3. Double-click the file to start the installation.
4. In the Welcome window, click Next.
5. In the License Agreement window, click Yes.
6. If a Read Only File Detected window pops up, click Yes.
7. After the installation finishes, click OK.
8. Reset all corresponding devices.

Cisco Unified IP Phone Model 7911Gand 7906G Alternate Firmware format

The Cisco Unified IP Phone Model 7911Gand 7906G Firmware version 9.2(3) is also supplied ina zip file, as an alternative in case a Cisco Unified CallManageris not available to run the executable installer program. The name of this fileis cmterm-7911_7906-sccp.9-2-3.zip.

After unzipping the firmware files, they should be manuallycopied to the appropriate directory on the TFTPserver.

Copyright© 2011 Cisco Systems, Inc. All RightsReserved

Recently I purchased a cheap Cisco 7911 phone off of Ebay. Now, we all know that Cisco doesn’t care about end users, and relies on product quality through their channel partners. If you didn’t buy it from a partner, then tough luck.

In this case, Ebay isn’t a partner, so I had to rely on a friend to download the latest SIP compliant firmware for the 7911 for me. The phone, as I had it, was configured to use Cisco’s SCCP ‘Skinny’ protocol, and talk to a CallManager server. I had other plans. A friend downloaded cmterm-7911_7906-sip.8-4-2.cop for me, which I promptly renamed to cmterm-7911_7906-sip.8-4-2.tar.gz. This allowed it to be ungzipped and untarred into a working directory called 7911.

Now, I already have a working tftp server on my network. I use it for all sorts of netbooting magic. For that reason, I’m not going to cover how to set up tftp, as that’s covered a million times over elsewhere on the internet.

The main task here, is to get the 7911 to load the term06.default.loads file from the tftp server. It would be nice if the 7911 would listen to the filename parameter that can be passed from DHCP, but sadly it seems to only be interested in term06.default.loads at the base of the tftp directory. I tried everything, from matching the hardware substring in dhcpd.conf, to symlinking the mac address to the right file. Ultimately, to keep everything tidy, I put the 7911 directory into my tftp boot directory, and ran the following command.

root@senior:/srv/tftp# for i in 7911/*; do ln -s $i . ; done
root@senior:/srv/tftp#

This runs through the contents of the 7911 directory, and symlinks them to the base tftp directory. Now, reset the phone with the following procedure.

With the phone turned off, press and hold # while inserting power, either via PoE or mains adaptor. In a second or so, the line buttons start flashing amber. Release # and dial 123456789*0# and then wait. Now is a good time to be running tail -f /var/log/syslog on your tftp server. All being well, you will see logs similar to that below. If this doesn’t work, or nothing appears on the phone display, wait 5 minutes and then try the procedure again, but use 3491672850*# instead.

Cisco Cp-7911 Sip Firmware

Dec 29 19:49:16 senior atftpd[13059]: Serving term06.default.loads to 172.24.32.28:49152
Dec 29 19:49:17 senior atftpd[13059]: Serving jar11sip.8-4-1-23.sbn to 172.24.32.28:49153
Dec 29 19:49:20 senior atftpd[13059]: Serving cnu11.8-4-1-23.sbn to 172.24.32.28:49154
Dec 29 19:49:24 senior atftpd[13059]: Serving apps11.8-4-1-23.sbn to 172.24.32.28:49155
Dec 29 19:49:44 senior atftpd[13059]: Serving dsp11.8-4-1-23.sbn to 172.24.32.28:49156
Dec 29 19:49:47 senior atftpd[13059]: Serving cvm11sip.8-4-1-23.sbn to 172.24.32.28:49157

Once it has finished the last file, give the phone a couple of minutes to install and reboot. After a successful reboot, it should be display a Cisco screen with the words ‘Unprovisioned’ at the bottom left. If you continue to watch syslog, you will see that it requests XMLDefault.cnf.xml, CTLSEP001E4AF3D34A.tlv and SEP001E4AF3D34A.cnf.xml on a regular basis. These files handle the provisioning of the phone, from defaults to individual per-phone settings. Further information on the contents of such a file can be found over here. Once you’ve written the required file, save it into the working directory and symlink it to the tftproot as before.

Cisco 7911 Sip Firmware Update Asterisk

You can then either wait for the phone to download the new file, or reboot the phone. Every time the phone boots, it will request term06.default.loads, as that informs it about the available firmware versions. If there are no changes, it will boot as normal.
